CNC Tool Wear And Offsets - How To Recover 1–2 OEE Points
If your OEE stalls in the low 80s while programs and staffing look fine, look at tool wear and offsets. Operators compensate in the wear table, feeds creep down, and first-article checks stretch. None of that trips a breakdown code, but it wrecks the Performance leg.
How tool wear turns into lost Performance
Performance is ideal cycle divided by actual cycle. Every second of extra cut, dwell or probing lowers that ratio. Wear pushes you there in three ways:
- Feed overrides slide below 100 percent to protect finish or chatter - tiny per part, big over a shift.
- Extra passes or lighter stepdowns creep into the program - useful as a stopgap, deadly when permanent.
- Offset changes push the machine into more conservative paths - comp is fine, comp drift is not.
A quick sanity check: if the ideal cycle is 60.0 s and actual drifts to 61.2 s, Performance becomes 60.0 ÷ 61.2 = 0.980. That is roughly a 2.0 pt hit on the Performance leg before you touch Availability or Quality.
Set thresholds the floor will follow
Start with thresholds that reflect typical tolerances, then tune per cell. These are practical, not theoretical. Use them to trigger an action, not a lecture.
| Tool class | Wear or offset drift trigger | Action |
|---|---|---|
| Finishing end mill, ±0.02 - 0.05 mm features | Wear diameter change ≥ 0.03 mm or three offset edits in one shift | Replace or swap to a fresh sister tool, reset feed override to 100 percent |
| Roughing end mill | Wear diameter change ≥ 0.20 mm or cycle time +3 percent vs last clean run | Swap insert or tool, restore original stepdown and radial engagement |
| Turning insert CNMG finishing | Nose wear land ≥ 0.15 mm or two offset bumps in one shift | Index insert, verify surface finish, lock offsets |
| Boring bar for H7 fit | Radial offset drift ≥ 0.01 mm or probe correction every run | Replace insert sooner, reduce cycle by removing redundant probe |
| Drill in stainless | Cycle time +5 percent vs baseline or chip evacuation alarm twice in a shift | Shorten peck, replace drill if margin wear seen, restore baseline feeds |
Two simple rules keep this honest: an offset changed more than twice in a shift means the tool is done, and any cycle time that climbs past +3 percent vs last clean run demands a correction that same shift.
First-article routine that prevents the slide
Right after a tool change, program change or maintenance, run a tight first-article routine. It takes minutes and saves hours.
- Load the tool and apply nominal wear offsets only.
- Run one part with feed override at 100 percent.
- Probe or gauge the two or three critical features.
- Update wear offsets once, within your limits, then lock the override again at 100 percent.
- Record the cycle time, tool ID, and offset delta in MDCplus.
Do not ratchet offsets throughout the shift. One correction and lock. If the next check fails or cycle time creeps, you hit a threshold - swap the tool or fix the cut.
Make the loss visible - one tile, two plots
A single MDCplus tile can carry the whole story for a cell:
-
Header shows Performance for the shift and week to date.
-
Left axis is actual cycle time, right axis is tool age in minutes of cut.
-
Plot a line for cycle time, a stepped line for cumulative tool age, and annotate each offset change as a dot with the delta in mm.
-
Add a small badge with feed override average for the last 20 parts.
What it reveals: cycle time rises as tool age climbs, offsets hop upward right before the worst parts, feed override quietly sits at 92 percent. Once people see this, the conversation changes from opinions to physics.
With networked CNCs, MDCplus reads status, cycle completions, overrides and wear offsets directly from the control to the server - no edge boxes, no manual retyping.
Two ways to cut back the loss today
Sister tooling with a hard swap point. For the constraint machine, define a maximum tool age in minutes of cut or number of parts where quality is still safe and cycle time is still flat. Swap to a pre-set sister tool at that point. The swap is cheaper than the drag.
Baseline, then lock. Capture a clean 10-part average right after first article. If the next 10-part average drifts +3 percent or more, the lead stops the job and applies the threshold playbook - replace tool, reset override, remove emergency passes.
Micro-case - two points back without touching the program
Aluminum gearbox housing, 4-axis mill. Ideal cycle 420 s. Actual averaged 436 s by Friday afternoon. Performance was 420 ÷ 436 = 0.963 - 3.7 pt loss on Performance. Offsets showed three edits on the finishing end mill, feed override averaged 93 percent, tool age 180 minutes. The team swapped to a sister tool at 150 minutes cut-time, restored the override to 100 percent, removed a “temporary” spring pass. New actual 427 s. Performance returned to 420 ÷ 427 = 0.984 - roughly 2.1 pt back, no program rewrite.
What to collect and how to keep it clean
You do not need a data zoo. Tie everything to the part and the tool.
- Tool ID, insert edge, and minutes of cut or parts since last change.
- Wear offset edits with sign and size.
- Cycle time by part, not by batch.
- Feed override sample or average.
- First-article result and the one allowed offset correction.
If you run some manual cells, mirror the same fields on a simple tally with tick boxes. The goal is the same - connect offset drift and tool age to cycle time, then act.
Pitfalls that sink this work
- Chasing finish with override instead of the tool. Overrides below 100 percent should be a red flag, not a new normal.
- Probing every part to cover a dying tool. Probing is not quality when it replaces stable cutting. Use the threshold and change the tool.
- Moving thresholds weekly. Pick limits, live with them for a month, then adjust by data.
- Treating offset edits as harmless. They are a cost. Count them and cap them.
Tie-in with OEE
Everything above is about the Performance leg, but it bleeds into Availability and Quality if you let it. Probing and spring passes masquerade as runtime while removing real throughput, scrap rises as tools limp past their life, and stop-start tinkering creates micro-stops. If you have not read it yet, pair this routine with your micro-stop hunt and the practical OEE measurement guide. Together, they give you the numbers you can trust and the points you can claw back.
Tool wear is not just an insert budget - it is a throughput tax. Set hard, visible thresholds for wear and offset drift, run a strict first-article check, and keep overrides at 100 percent unless you are cutting a genuine exception. Put cycle time and tool age on one MDCplus tile and let the picture force the right swap at the right time. Expect a clean 1 to 2 point lift in Performance once the drift stops and the cuts go back to plan.
