Top HAAS CNCs Error Codes Explained & How To Fix

Below we walk through some of the most frequent Haas alarms, their causes and how to address them.



1. Alarm 102 “SERVOS OFF”

This alarm indicates that the servo amplifiers or axis drives have been disabled while the machine is attempting motion. Underlying issues may include loose wiring, servo motor faults or a drive fault.
Typical causes:

  • An emergency stop or door open condition
  • A cable connection to the servo amplifier is loose or damaged
  • A faulty servo drive or amplifier
  • An encoder signal missing or a motor brake engaged

How to fix it:

  • Confirm that all emergency stops and door interlocks are released and the machine is ready
  • Check the servo amplifier LED status and fault codes
  • Inspect the servo motor cables and ensure they are securely connected and undamaged
  • If wiring checks out, test the servo amplifier per the manufacturer’s troubleshooting guide
  • If replacement is needed, schedule the repair during planned downtime to avoid disrupting production

2. Alarms 103-105 “SERVO ERROR TOO LARGE”

These alarms (103 for X axis, 104 for Y axis, 105 for Z axis) indicate that the respective axis cannot follow the commanded position - meaning servo error is too large or encoder feedback is out of tolerance.
Typical causes:

  • Mechanical binding (for example, ballscrew damage or excessive friction)
  • A contaminated or faulty encoder cable or motor-encoder interface
  • Incorrect machine parameters related to encoder counts versus screw pitch
  • A motor brake that fails to release properly during zero return or motion

How to fix it:

  • Manually jog the axis and listen or feel for binding or irregular motion
  • Inspect the encoder cable for damage or contamination; reseat connectors
  • Verify the machine parameter settings against the control’s specification
  • Test the motor brake to confirm it releases properly before servo enable
  • After corrections, perform a zero return and monitor for recurring alarms
  • If still unresolved, escalate to service for deeper diagnostics

3. Alarms 161-164 “AXIS DRIVE FAULT”

These codes indicate a fault at the drive amplifier level (161 = X axis drive fault, 162 = Y, 163 = Z, 164 = A) on Haas machines. The amplifier has detected conditions such as over-current, short circuit or internal failure.
Typical causes:

  • An amplifier that is overheating or has an internal fault
  • A motor winding short or encoder fault leading to drive fault
  • Power cable damage or grounding issues
  • Cooling fan failure inside the drive cabinet

How to fix it:

  • Verify amplifier cooling: check internal fan, airflow and cabinet ventilation
  • Disconnect power and inspect motor cable insulation for breaks or shorts
  • Swap drive channels (if permitted) to determine whether the fault is axis-specific or drive-specific
  • Replace the drive or motor only after full isolation and verification
  • After repair, monitor the machine for recurrence - persistent faults often indicate deeper issues

4. Alarm 20000 Series “Informational Messages”

Codes in the 20000-series (for example 20000–20017) on Haas machines are informational or warning messages rather than full faults. They may indicate conditions such as missing components, electronics overheat or memory issues.
Typical causes:

  • Machine boot-up memory or communication messages
  • Ancillary components flagged (such as missing cards or modules)
  • Temperature or air-pressure warnings

How to fix it:

  • Review the message: if it references non-critical hardware, note it while continuing production
  • For temperature or air-pressure warnings: check cabinet thermostat, ensure cooling and verify incoming air pressure
  • Log the event - if warnings increase, schedule preventive maintenance to avoid future production-impacting faults

5. Alarms 128-132 “Super Travel / Tool Not Clamped / Power Down Failure”

Codes in this range cover conditions such as axis travel beyond limits (super travel), tool or chuck unclamped or power down failure. For example code 130 appears as TOOL UNCLAMPED on mills or CHUCK UNCLAMPED on lathes.
Typical causes:

  • Tool magazine failed to clamp the tool correctly
  • Work axis exceeded travel limits due to a mis-loaded fixture
  • Power voltage issues such as brown-outs or unstable supply

How to fix it:

  • Check tool magazine operation: observe clamp/unclamp cycles, clean magazine and collet system
  • Verify the part fixture, offsets and load-setup are correct to avoid axis over-travel
  • Inspect the incoming power feed: verify voltage stability, proper grounding and no brown-out conditions
  • Reload program and offsets if the fixture or offset change was applied incorrectly

6. Alarm 108 “X SERVO OVERLOAD

The machine reports that the X axis servo motor is overloaded - it cannot maintain the required torque or load. This is a common issue on heavy or worn machines.
Typical causes:

  • Mechanical binding on the X axis (for example worn ballscrew or debris in guides)
  • Excessive feed rate or unintended cutting conditions
  • Motor current parameter or servo tuning not matched to load

How to fix it:

  • Manually jog the X axis slowly and feel for binding or roughness
  • Inspect the ballscrew, linear guides, bearings and lubrication
  • Check the current feed and spindle load in the program and reduce if necessary
  • Review servo parameters and amplifier status; inspect the signal chain to the motor if mechanical checks pass

7. Alarm 124 “LOW BATTERY”

This alarm indicates that the machine’s control backup battery (which holds parameters and memory) is low or faulty. That can lead to memory or parameter loss.
Typical causes:

  • The control was powered-down improperly
  • The battery has aged beyond its service life
  • A drop in control memory voltage was detected

How to fix it:

  • Replace the backup battery per the machine’s service guidelines
  • Ensure machine power-off procedures are followed to protect memory and parameters
  • After battery replacement, verify all parameters, offsets and backups are intact

8. Alarm 130 “TOOL UNCLAMPED” / “CHUCK UNCLAMPED”

This code appears when the machine detects the tool or chuck is not properly clamped while machining - a frequent fault in high-mix job shops.
Typical causes:

  • A faulty tool-clamp sensor
  • Tool magazine misalignment or wear
  • Incorrect tool number called in the program
  • Insufficient spindle load to engage clamp or chuck

How to fix it:

  • Inspect the tool magazine and clamping mechanism for wear or damage
  • Verify the tool holder is correctly seated and the magazine indexes properly
  • Check that the program’s tool number and actual tool match
  • Test the clamping sensor or circuit and replace if faulty

9. Alarm 172 “DOOR OPEN – SPINDLE STILL TURNING” / “PALLET UNCLAMP TIMEOUT”

On lathes this code means the door opened while the spindle was still turning; on mills it means the pallet unclamp cycle exceeded the allowed time. These are safety and automation-cycle related faults.
Typical causes:

  • On lathe: door switch failure or operator error
  • On mill: pallet clamp/unclamp cycle delayed due to sensor fault, mis-alignment or hydraulic/pneumatic issue

How to fix it:

  • On lathe: inspect the door switch wiring and interlock logic; ensure spindle stops fully before door opens
  • On mill: test the pallet clamp/unclamp sensors; verify timing of hydraulics or pneumatics and check alignment pins
  • Reset the cycle and log any repeat events for follow-up maintenance

10. Alarm 174 “TOOL LOAD EXCEEDED”


This code is triggered when the machine detects the load on the current tool has exceeded the safe or programmed threshold. It often appears on both mills and lathes.
Typical causes:

  • Worn or broken insert
  • Incorrect tool length or radius offset entered in the control
  • Feed rate too high or part material harder than specified
  • Gradual tool wear or chipping that increases load over time

How to fix it:

  • Inspect the tool and holder: check insert condition, seating and balance
  • Review tool offsets in the control and ensure correct values
  • Check program feeds and speeds for that tool step and reduce if necessary
  • Monitor spindle load trends - if load gradually increases over many parts, consider reducing tool change interval

Keeping production running smoothly on Haas CNC machines means not only reacting to alarms but understanding them. The codes above are among the most frequent and offer high value. By diagnosing the correct root cause - and not just chasing symptoms - you preserve machine availability, protect production schedules and keep your manufacturing floor running.

Make sure your maintenance team and operators have quick access to an alarm-code list and actionable fixes. By making alarm diagnosis part of your process rather than an exception, you shift from firefighting downtime to proactive uptime.
