Invisible Micro-Stops That Drag Your OEE Down
The invisible 6 % – micro-stops that drag good lines from 85 to 79 OEE
Micro-stops are like sand in a gearbox – each grain is small, together they grind your grade down.
Plants that brag about an 85 % score often bleed six whole points to jolts lasting less than five minutes. They don’t trigger the downtime log, the ERP, or anyone’s pager – yet they add up to a full shift of lost production every month.
What counts as a micro-stop
-
Duration – 10 sec to 5 min
-
Frequency – dozens a shift
-
Symptoms – conveyor nudge, sensor fault reset, chip clear, part jiggle
Anything longer than five minutes usually hits the official downtime list. Anything shorter sinks into the noise floor – unless you shine a light.
Why the benchmark article hints at it but doesn’t dive deep
Our OEE grade case studies focus on big hitters – breakdowns, changeovers, scrap. Micro-stops sit in the gray zone where Availability meets Performance. You see the effect (cycle time drift) long after the cause (a three-second sensor flicker).
The math behind the missing six points
Line running 50 parts per hour, 16 h a day:
-
85 % OEE = 680 good parts/day
-
Thirty 40-second stutters per shift = 40 min lost/day
-
New OEE ≈ 79 % → 632 good parts/day
Forty-eight parts vanished. Two pallets off the truck.
How to make micro-stops visible
Tool | Setup cost | Signal captured | Install hint |
---|---|---|---|
High-resolution state tag (sec-level) | None – built into most PLCs | Cycle start → cycle complete | Turn polling rate to 1 sec in MDCplus |
External current clamp | €30 | Motor on/off ripple | Good for legacy drills and presses |
Capacitive part sensor | €45 | Part present vs missing | Mount at out-feed chute |
Andon cord with soft button | €8 | “Nudge required” | Lets operators flag jams instantly |
Log all four into MDCplus. Anything that pauses motion for more than one cycle equals a micro-stop.
Daily micro-stop hunt – 30 min Gemba loop
Minute | Action | Owner | Outcome |
---|---|---|---|
0–5 | Pull yesterday’s micro-stop Pareto | Team lead | Top three offenders highlighted |
5–15 | Go see the machine | Crew | Confirm root – chip pack, loose sensor, worn gripper |
15–25 | Try-storm fix | Same shift | Quick shim, air blast, tighten cable |
25–30 | Log fix + photo in MDCplus note | Lead | Proof for audit and next crew |
Repeat daily until the Pareto flattens. Move to next cell.
Quick wins that killed >1 % loss each
-
Swap cheap photo-eye for retro-reflective – solved missed count on dark parts.
-
Add air pulse every ten cycles – chips stop clogging the laser cutter lens.
-
Spring-load pallet locator pins – no more hand taps to seat parts.
Each job cost under €100 and ten minutes – saved over 1 % OEE.
When data beats stopwatch politics
Operators hate being timed. A one-second PLC tag never lies, never blames. Post the micro-stop heat map on the tier board – red blocks dare the crew to beat them.
What to Read
If you are looking for top notch read and learning, here is a small list with big benefits:
-
Toyota Kata – Mike Rother – drills the habit of small, daily experiments.
-
Making Common Sense Common Practice – Ron Moore – ties reliability to Lean production.
-
Maintenance Planning and Scheduling Handbook – Richard “Doc” Palmer – shows why planned downtime is cheaper than surprise downtimes
