Measuring OEE in practice – from formula to bullet-proof data

You read What Is Overall Equipment Effectiveness? and you know the math. You skimmed the OEE Grade Case Studies and saw how the best plants flirt with 85 percent. The gap is the messy middle: collecting data solid enough to benchmark without another audit forcing you to rewrite half the logbook.

1. The OEE formula – one-paragraph refresher

Availability × Performance × Quality = OEE. Availability strips out planned and unplanned downtime, Performance compares actual cycle time to the ideal, Quality removes rejects. Miss on any leg and the grade limps. Read the full formula breakdown.

2. The bare-minimum data set

Factor Must-have tag Where it lives Typical source
Run time Spindle active flag CNC control Fanuc, Siemens, Haas status bit
Planned downtime Shift schedule table MES / Excel Scheduler export
Ideal cycle time Part program header CNC NC file #CYCLE_TIME macro
Actual cycle time Machining complete timestamp CNC log MTConnect or OPC UA
Total pieces Part counter CNC variable #504 on Fanuc
Good pieces Scrap flag per part Quality log Operator keypad + QC report

These six points feed all three OEE legs. Anything missing forces guesswork.

3. Mapping the Six Big Losses to real tags

Loss Signal combo Sanity check
Equipment failure Spindle active goes 0 and alarm bit flips 1 Downtime ≥ 5 min
Setup and adjustment Program ID changes Run time zero, spindle stops
Idling and minor stops Spindle drops 0 for <5 min, alarm stays 0 Count events per shift
Speed loss Actual cycle > Ideal cycle ×1.05 Look for tool-wear pattern
Scrap Scrap flag = 1 Reject reason code present
Rework Good piece counter unchanged after extra machining Extra cycle on same part ID

Log each loss in its own column. When the case-study article talks about killing hidden losses, this is how you spot them.

4. Two collection modes that work on real lines

  1. Manual tally sheet – paper never crashes

    • Operator notes scrap count and break causes at end of hour.

    • Cost: a clipboard and honesty.

    • Risk: fat-finger errors – run a weekly audit.

  2. Direct CNC pull – the no-hardware option

    • Tap the control via MTConnect, OPC UA or vendor API.

    • Stream status bits, counters, timestamps straight to the MDCplus server.

    • Cost: one network drop and a five-minute credentials setup.

    • Bonus: second-level resolution exposes micro-stops without stopwatch drama.

Mixed modes clutter the story. Pick one and stick to it.

5. Quick sanity checks before you publish a number

  • Impossible availability – if planned time is eight hours and run time logs at 8.3, the clock is wrong.

  • Cycle-time outliers – any part over 200 percent of ideal throws a flag.

  • Quality over 100 percent – scrap counter missed a reject.
    Run these in SQL or Excel; bad rows pop instantly.

6. Weekly validation huddle

Day Agenda Time box
Friday Review flagged anomalies 10 min
Friday Randomly sample one shift sheet vs CNC log 5 min
Friday Sign-off – numbers good enough to publish 2 min

Keep the meeting under 20 minutes or no one comes back.
