Okuma MS-320H - Small Shop Efficiency Booster
Compact Automation, Designed for Production Flexibility
At just 1,580 × 3,120 mm, the MS‑320H offers a 56% space reduction compared to previous models. This is crucial for smaller shops constrained by limited floor space. The integrated loading hatch enables part loading and unloading in just 5.3 seconds, removing the need for constant operator presence and supporting lights-out operations. The system also supports mobile collaborative robots and features an 8-port hydraulic/pneumatic table, making it adaptable to changing production needs.
Precision, Chip Control, and Operational Stability
The MS‑320H features a high-speed No. 40 spindle operating at 15,000 rpm and delivering 25 kW peak power. This ensures robust cutting performance for a wide range of materials, especially small, high-tolerance parts. The machine’s vertical-table design and sloped stainless covers provide highly effective chip management, preventing downtime from chip accumulation.
Optional features like the “sludgeless tank” reduce maintenance requirements to a three-year cycle, freeing up staff resources. The Thermo-Friendly Concept compensates for thermal drift, preserving dimensional accuracy even in environments without climate control. The integrated ECO Suite Plus optimizes energy use through idle shutoffs and other smart resource controls.
A Strategic Asset for Small-Batch Production
For small shops handling short runs, frequent changeovers, or prototype jobs, the MS‑320H delivers speed and stability. It reduces lost motion via a rapid tool changer and achieves traverse speeds up to 60 m/min with 1 G acceleration—ideal for cycle-time-sensitive environments.
With optional AI diagnostics and on-axis monitoring, emerging faults are caught early, preventing unplanned downtime and safeguarding output consistency.
Competitive Comparison
When compared to other industry options, the MS‑320H stands out:
-
Sugino SC‑H30a: Compact and optimized for long unattended cycles with effective chip evacuation. However, it lacks the integrated automation flexibility found in the MS‑320H.
-
DMG MORI NHC-series: Offers premium automation and modular pallet systems. Ideal for scalability, but carries a significantly higher investment and larger footprint.
-
Haas EC-400: A value-driven solution with twin-pallet automation. While cost-effective, it doesn’t match the MS‑320H in chip handling sophistication or integrated automation capabilities.
Feature | Okuma MS‑320H | Sugino SC‑H30a | DMG MORI NHC-series | Haas EC-series |
---|---|---|---|---|
Footprint & compactness | Very compact (56% smaller) | Compact, rigid | Larger, scalable | Moderate |
Automation readiness | Integrated loader, cobot | Interface ready | Modular pallet/robot cells | Twin-pallet + add-on robots |
Chip management | Vertical table, conveyor | Center-trough | Standard conveyors | Standard conveyors |
Uptime & autonomy | Lights-out enabled | Long unmanned cycles | Fully automated lines | Shift-based automation |
Price tier | Mid-to-high | Mid-range | Premium | Entry–mid |
Final Take
For small and mid-size shops that need flexible automation, chip-stable performance, and minimal operator dependency, the Okuma MS‑320H is a highly competitive solution. It bridges the gap between entry-level HMCs and premium automation platforms by delivering high-speed machining, lights-out potential, and sustainable operation in a compact, scalable package.
